Model: JDM-196
The remote control and aluminum box are delivered with the vehicle
Scale: 1/14
Dimensions: Length 728mm; Width 218.5mm (flat width); Height 277.5mm (car roof)
Vehicle weight: 10kg. Total packaging weight 18KG
Rated load of lifting platform: 10kg
Maximum lifting of lifting platform: 14
Rated load of tail trailing arm: 3kg
Main configuration:
Gearbox: three-speed transmission, speed ratio first gear 1/2.72; second gear 1/6.7; third gear 1/17.4 Transfer case:
Transmission-disconnectable axle: wheel-side reduction axle
Directional reversing valve: 4-way upgraded reversing valve
Oil pump: ductile iron micro oil pump, working pressure 3MPA, use No. 32 hydraulic oil or No. 46
Remote control: PL18 LITE version
Engineering lights: standard, using BitRC's multi-mode engineering lights. Full vehicle lighting: standard
Winch: standard KKRC high-torque metal winch
Rope tightener: standard 4 sets
Power supply voltage: 12V, using 3S lithium battery (135mm long, 43mm wide, 30 mm high, within the size, battery and power display need to be purchased separately)
